JL Audio W3

$469.99

Powerful, Precise Bass in Compact Spaces
The W3v3 series subwoofers deliver deep, punchy bass and high-fidelity performance at moderate power levels. Built on technologies from JL Audio’s flagship W7 line, they combine reliability, compact design, and exceptional output, making them ideal for medium-power applications.

Engineered for Optimal Sound
Designed for sealed or ported enclosures, W3v3 subs offer impressive clarity, output, and accuracy without requiring excessive space or power.

Advanced Motor Technology
Dynamic Motor Analysis (DMA) ensures consistent, linear motor force for tight, low-distortion bass and outstanding sound quality across a wide operating range.

Durable Cone Construction
A mineral-filled polypropylene cone with a rubber surround delivers clean, powerful bass with the durability to handle high-output listening. A signature JL Audio medallion adds a sleek finishing touch.

Maximize Output with Larger Sizes
For those with space, the 13.5-inch model offers up to 54% more air displacement than the 12-inch version—translating to higher efficiency and greater output.

Customizable Design Options
Each sub includes a removable trim ring, with optional steel-mesh grille inserts available for added style and protection.

Flexible Power Handling Across Sizes

From the compact 6.5-inch (150W RMS) to the powerful 13.5-inch (600W RMS) model, the W3v3 line fits a wide range of vehicle setups and amplifier pairings.

  • Overall Diameter: 12.5 inches (318 mm)
  • Mounting Hole Diameter: 11.0625 inches (281 mm)
  • Mounting Depth: 6.5 inches (165 mm)
  • Driver Displacement: 0.075 cu ft (2.12 L)
  • Net Weight: 14.5 lbs (6.6 kg)
  • Nominal diameter: 12.0 in / 300 mm
  • Overall diameter: 12.5 in / 318 mm
  • RMS power handling: 500 W
  • Frequency response: 22 – 200 Hz
  • Sensitivity: 87.15 dB (1 W / 1 m)
  • Mounting (top) depth: ~ 6.65 in
  • Free-air resonance (Fs): ~ 26.72 Hz
